TokNAV – High Performance GNSS Receiver – T30 Rover Set
US$3,000.00 Excl. GST/VAT
T30 is a fully-featured GNSS receiver designed for long battery life and high precision. It includes an advanced positioning module supporting full-system and multi-frequency satellite signal tracking. Equipped with 4G universal connectivity, Bluetooth, WiFi, a 5W data radio, and a large-capacity battery, it can operate continuously for up to two days on a single charge. The device integrates a high-precision inertial navigation system combined with AR and laser technology for AR stakeout and laser measurement, and augmented reality plotting, making surveying tasks more efficient and convenient.
Delivery Terms:
DDP, Australia;
DAP, Global shipping except Australia
Warranty:
OEM Warranty, 2 year;
Lead Time:
2 weeks plus transport.
Key Features Of T30 GNSS Receiver
TokNAV T30 GNSS receiver can be set up as both rover and base station with up to 5w radio. With its large volume battery on board, it can operate up to 48 hours with single charge. And it also supports AR stakeout and laser measurement.
If you only need a rover function GNSS receiver, please consider T5 series RTK Rover;
If you only need a basic base station and rover function GNSS receiver, please consider T10 Pro series GNSS Receiver;
If LCD touch screen function is required on site, please upgrade to T20 Pro;
If image survey are required for site application, please upgrade to T30 Pro or T40 Pro series;
Laser Measurement
Equipped with a high-precision millimeter-level laser ranging module, combined with high-precision inertial navigation for accurate laser targeting in complex environments.
AR Real-Time Stakeout
Utilizes a professional ultra-wide-angle camera to provide high-definition real-time plotting functionality, making layout tasks more accurate and convenient.
Linux Intelligent System
ARM Cortex-A7 + Linux, the intelligent system platform, brings efficient computing and unlimited expansion of product functions to users.
PPP Supported
Precise Point Positioning (PPP): Leverages precise satellite orbit/clock products for single-receiver positioning, which allows to acquire high precision position anywhere on earth without any subscription.
Full System GNSS Reception
The receiver integrates a high-precision positioning module, utilizing 1408 channels to support a comprehensive range of signals including BDS B1I/B2I/B3I/B1C/B2a/B2b(PPP), GPS L1/L2/L5, GLONASS L1/L2/L3, Galileo E1/E5a/E5b/E6(PPP), and QZSS L1/L2/L5.
Tilt Measurement
T30 has the IMU module. Fast initialization and up to 60° inclination.
Combined Antenna
The new four in one antenna integrates GNSS, WIFI, Bluetooth and 4G, with smaller volume and better signal.
PPK Processing Supported
PPK processing is supported when there is no stable RTK data link available.
Long Endurance
Built-in high-capacity lithium battery ensures continuous working time of more than 48 hours under normal operation.
IP68 Design
Industrial design, solid magnesium alloy shell, in line with IP68 design requirements, safe and reliable.
4G Modem
T10Pro has an internal 4G Modem that operates with more cellular network signals. A fast internet connection is guaranteed.
Technical Parameters
Downloads & Tutorials
TSurvey 2.0 Survey Software Tutorial
T30 Unbox and Test Videos
Unbox & Test Videos for T30 GNSS Receiver
2:04
2:04
2:04
Package And Sets
T30 (RTK rover set)
Packing List:
1 unit of T30 GNSS Receiver;
1 unit of T30 controller;
1 unit of controller bracket;
1 unit of UHF antenna;
1 unit of charger and USB-C cable;
